Zhejiang Wellnit Mechanical Technology Co.,Ltd
Adhered to customer satisfaction as the goal, to pioneering innovation as the driving force, to honesty and trust worthiness as the principle, to quality and low price as the pursuit!
|
Product Details:
Payment & Shipping Terms:
|
| Brand Name: | Wellnit | Model: | SHTW-35 |
|---|---|---|---|
| Torque: | 4866-48666 N.m | Bolt Size: | 64-120 M |
| Weight: | 45 KG | Square Drive: | 2-1/2" |
| High Light: | hydraulic torque wrench,hydraulic torque machine |
||
Hydraulic Bolting Tools Handheld Hydraulic Tools Industrial Bolting Solution
Hydraulic Torque Wrench Description:
Hydraulic wrench is a hydraulic tool for fixing and removing large bolts. It is composed of four types of
products, such as hydraulic wrench, power source, high pressure oil pipe and sleeve.
Driven hydraulic universal hydraulic wrench, a wide range of applications.
The material of Hydraulic Torque Wrenches( low profile hydraulic torque wrench) are Aluminum-Titanium
alloy and high strength alloy steel for increased strength.
SHTW series is the professional hydraulic torque wrench WREN vigorously extends in international
market.
Its raw material is aluminum-titanium alloy which makes the wrench light and high intenes .
SHTW series has 9 models with the range from 183N.m to 48666N.m；covers the most of bolts size, and
be the most comprehensive available in the market.
1. Powerful, Accurate, Durable and Dependable
2. Made with high grade aluminium-titanium alloy and high strength alloy steel
3. Max Working Pressure: 700Bar
4. +/- 3% Accuracy
5. 360*180 degree uni-swivel hose coupling, Most Fit Friendly
6. Ease of Repair
7. Finite Element Analysis - Longer Tool Life
8. One Year Warranty
Product Features
Patented integrated body design, more sturdy and durable
Rotary-return mechanism design, never-jam mechanism.
Hands-free operation, making the use more safety.
Slim nose radius and 360°×180° swivel hose connection allow easier positioning in confined space.
High repeatability, with accuracy±3%
360°reaction arm, makes the wrench get better supporting
Standard working pressure: 700par.
|
Model
|
Torque |
Bolt Size |
Weight |
Square Drive |
|
SHTW-1
|
183-1837 |
16-36 |
2 |
3/4” |
|
SHTW-3
|
451-4512 |
22-48 |
4 |
1” |
|
SHTW-5
|
752-7528 |
27-56 |
7 |
1-1/2” |
|
SHTW-8
|
1078-10780 |
30-64 |
9.1 |
1-1/2” |
|
SHTW-10
|
1551-15516 |
36-72 |
13.1 |
1-1/2” |
|
SHTW-15
|
2063-20627 |
39-80 |
21 |
2-1/2” |
|
SHTW-20
|
2666-26664 |
42-90 |
25 |
2-1/2” |
|
SHTW-25
|
3472-34725 |
48-100 |
31 |
2-1/2” |
|
SHTW-35
|
4866-48666 |
64-120 |
45 |
2-1/2” |
Machine Parameter
|
Model
|
Torque N.m |
Bolt Size M |
Weight Kg |
Square Drive
|
|
SHTW-35
|
4866-48666 |
64-120 |
45 |
2-1/2”
|
1. Made of high-tech aerospace materials aluminum-titanium alloy and ultra-high strength alloy steel, the
fuselage is formed in one body, and the strength and toughness of the fuselage are strengthened in an
all-round way.
2. tubing joint with 360 degree x 180 degree rotation, free of space restriction and free operation.
3. The trigger-type lock is easy to press, and the 360-degree fine-tuning reaction arm can be fixed on a
solid support at will.
4. precision ratchet, accuracy up to + 3%
5. multifunctional accessories meet your requirements, and can be customized.
Standard Configuration
Special Pump for Hydraulic Torque Wrench
The pump body is made of aluminum titanium alloy
Light Weight
Easy to Carry
Hydraulic Connecting Hose
Four layers nylon design
Light Weight
Small size
High bending radius
