Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type

Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type
Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type
video play

Large Image :  Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type

Product Details:
Place of Origin: China
Brand Name: Wellnit
Certification: ISO9001
Model Number: OCE-325
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2800
Packaging Details: Plywood box
Delivery Time: within 3days
Payment Terms: T/T,
Supply Ability: 15 sets / month
Contact Now
Detailed Product Description
Electric Power: 2000W Machine Feed Way: Automatic Feed
Machine Working Range: 168-325mm Wall Thickness: Less Than 30mm
High Light:

Clamshell Electric Pipe Cutter

,

Stainless Steel Pipe Bevel Cutter

,

Pipe Duplex Torch Beveler

Duplex stainless steel pipe cutting and beveling machine electric type clamshell type pipe cutter



machine introduction



This series of external mounted electric pipe cutting and beveling machine is easy to install and convenient to use. It has
features of simple maintenance, small installation space, and quick installation. It's widely used in long distance pipeline,
power plants, nuclear power, petroleum, chemical, natural gas, boiler plant, pharmacy, pipeline as well as the pipeline
installation and repair work sites.
This machine is ideal for all types of pipe cutting, beveling and end preparation. The split frame design allows the machine
to split in half at the frame and mount around the OD of the in-line pipe or fittings for strong, stable clamping. The equipment performs precision in-line cut or simultaneous cut and bevel, single point and flange facing operations, as well as weld end preparation on open ended pipe. It can be used on pipe size from 1” to 56" of most wall thicknesses and materials.

Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type 0
Pipe Size: 25-1430 mm or 1-56 inch
Wall thickness (standard):≤35
Wall thickness (heavy duty):≤110 mm
Cutting speed: 42 r/min - 8 r/min
Product material: chrome molybdenum steel, low temperature steel, titanium alloy steel, etc.

machine specification

Duplex Stainless Steel Pipe Cutting And Beveling Machine Electric Clamshell Type 1

Features:

1. Low axial & radial clearance.
2. Small working radius, suitable for any working situation.
3. Cutting and beveling at the same time.
4. Can be opened to use on pipe in the wall or no end open pipe.
5. Cold cutting work methods, which don't damage the pipe.
6. Multiple bevel joint types: V, U, J, compound and counter boring etc.
7. Customize the machine according to your requirements.



Tag:

pipe cutter and beveler,

pipe bevel cutter,

clamshell pipe cutting machine
